Semi Automatic Cartoning Machine

Semi Automatic Cartoning Machine

ZHJ-50

Semi Automatic Cartoning Machine
The Semi-Automatic Cartoning Machine can handle wide range of cartoners to accept various containers, bottles,blister packs, pouches, sachets or tube.
Semi Automatic Cartoning Machine

Features

  • Small footprint is ideal for space sensitive operations.
  • User friendly design requires only one operature.
  • Simplified engineering design allows for ease of maintenance.
  • Constructed with materials that meet G.M.P.
  • Safety guarding.

OPTIONS

  • Hot stamp imprinter for coding expiration date or series number on the box.
  • Hot-melt glue sealing cartoning Machine is available.
  • Modification for automatic infeed system.

Specifications

Model ZHJ-50
Capacity 20-50 boxes/min
Box Size L(40-165)mm×W(12-80)mm×H(12-80mm
Box Quality requirement 250-350g/m2
Working Pressure 0.5-0.8Mpa 150L/min
Motor power 220V 50Hz 1.5KW
Overall dimension 1100×1500×1900
Machine weight 450kg
